豪沃克xwall2.9版发布

豪沃克2.9版发布,新增陶板分析以及完善板块分析,可以分析平面类型板块包括矩形\三角形\原形\梯形\以及其他任意形状,任意支撑条件 并可以考虑洞口等选项,提供控制包括: 支撑加密, 圆弧分段加密,三角形面积控制,角度控制等, 新增陶板分析功能,可以从cad中导入陶板断面图,软件分析生成四面体图形并进行处理,得到相应的各类型图形并提供支座反力汇总等 [quote] 悬臂玻璃挠度图[/quote] [img]http://www.hwksoft.com/images/shell4disp.jpg[/img] [quote] 悬臂玻璃主应力图[/quote] [img]http://www.hwksoft.com/images/shell4maxp.jpg[/img] [quote] 四点支撑玻璃挠度图[/quote] [img]http://www.hwksoft.com/images/shell4pdisp.jpg[/img] [quote] 四点支撑玻璃主应力图[/quote] [img]http://www.hwksoft.com/images/shell4pmaxp.jpg[/img] [quote] 四点支撑玻璃最小主应力图[/quote] [img]http://www.hwksoft.com/images/shell4pminp.jpg[/img] [quote] 四点支撑玻璃剪应力图[/quote] [img]http://www.hwksoft.com/images/shell4pshear.jpg[/img] [quote] 四点支撑玻璃X方向主应力图[/quote] [img]http://www.hwksoft.com/images/shell4pstressx.jpg[/img] [quote] 三角形支撑玻璃挠度图[/quote] [img]http://www.hwksoft.com/images/shell3disp.jpg[/img] [quote] 三角形支撑玻璃主应力图[/quote] [img]http://www.hwksoft.com/images/shell3maxp.jpg[/img] [quote] 三角形支撑玻璃剪应力图[/quote] [img]http://www.hwksoft.com/images/shell3shear.jpg[/img] [quote] 简易陶板挠度图1[/quote] [img]http://www.hwksoft.com/images/claydisp1.jpg[/img] [quote] 简易陶板挠度图2[/quote] [img]http://www.hwksoft.com/images/claydisp2.jpg[/img] [quote] 简易陶板应力图1[/quote] [img]http://www.hwksoft.com/images/clayzstress1.jpg[/img] [quote] 简易陶板应力图2[/quote] [img]http://www.hwksoft.com/images/clayzstress2.jpg[/img]
